Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1114
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ASR Details
Register (itm) DEVID
Register DEVID Details
Register (itm) DTIR
Register DTIR Details
Register (itm) PERIPHID4
Field Name Bits Type Reset Value Description
7:0 ro 0x88 Value is 0b1S001N00 where S is secure
non-invasive debug state and N is non-secure,
non-invasive debug.
Name DEVID
Relative Address 0x00000FC8
Absolute Address 0xF8805FC8
Width 13 bits
Access Type ro
Reset Value 0x00000020
Description Device ID
Field Name Bits Type Reset Value Description
NumStimRegs 12:0 ro 0x20 Number of stimulus registers
Name DTIR
Relative Address 0x00000FCC
Absolute Address 0xF8805FCC
Width 8 bits
Access Type ro
Reset Value 0x00000043
Description Device Type Identifier Register
Field Name Bits Type Reset Value Description
7:0 ro 0x43 Indicates a Trace Source and the stimulus is
devifed from bus activity
Name PERIPHID4
