Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1121
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (tpiu) SuppSize
ITATBCTR1 0x00000EF4 7 ro x Integration Test ATB Control
Register 1
ITATBCTR0
0x00000EF8 10 ro x Integration Test ATB Control
Register 0
IMCR
0x00000F00 1 rw 0x00000000 Integration Mode Control
Register
CTSR
0x00000FA0 4 rw 0x0000000F Claim Tag Set Register
CTCR
0x00000FA4 4 rw 0x00000000 Claim Tag Clear Register
LAR
0x00000FB0 32 wo 0x00000000 Lock Access Register
LSR
0x00000FB4 3 ro 0x00000003 Lock Status Register
ASR
0x00000FB8 8 ro 0x00000000 Authentication Status Register
DEVID
0x00000FC8 12 ro 0x000000A0 Device ID
DTIR
0x00000FCC 8 ro 0x00000011 Device Type Identifier Register
PERIPHID4
0x00000FD0 8 ro 0x00000004 Peripheral ID4
PERIPHID5
0x00000FD4 8 ro 0x00000000 Peripheral ID5
PERIPHID6
0x00000FD8 8 ro 0x00000000 Peripheral ID6
PERIPHID7
0x00000FDC 8 ro 0x00000000 Peripheral ID7
PERIPHID0
0x00000FE0 8 ro 0x00000012 Peripheral ID0
PERIPHID1
0x00000FE4 8 ro 0x000000B9 Peripheral ID1
PERIPHID2
0x00000FE8 8 ro 0x0000004B Peripheral ID2
PERIPHID3
0x00000FEC 8 ro 0x00000000 Peripheral ID3
COMPID0
0x00000FF0 8 ro 0x0000000D Component ID0
COMPID1
0x00000FF4 8 ro 0x00000090 Component ID1
COMPID2
0x00000FF8 8 ro 0x00000005 Component ID2
COMPID3
0x00000FFC 8 ro 0x000000B1 Component ID3
Name SuppSize
Relative Address 0x00000000
Absolute Address 0xF8803000
Width 32 bits
Access Type rw
Reset Value 0xFFFFFFFF
Description Supported Port Size Register
Register Name Address Width Type Reset Value Description
