Appendix B: Register Details
Register CurrentTest Details
Register (tpiu) TestRepeatCount
Register TestRepeatCount Details
Register (tpiu) FFSR
Absolute Address 0xF8803204
Width 18 bits
Access Type mixed
Reset Value 0x00000000
Description Current Test Patterns/Modes Register
Field Name Bits Type Reset Value Description
PContEn 17 rw 0x0 Continuous mode.
PTimeEn 16 rw 0x0 Timed mode.
reserved 15:4 ro 0x0 Reserved
PatF0 3 rw 0x0 FF/00 Pattern
PatA5 2 rw 0x0 AA/55 Pattern
PatW0 1 rw 0x0 Walking 0s Pattern
PatW1 0 rw 0x0 Walking 1s Pattern
Name TestRepeatCount
Relative Address 0x00000208
Absolute Address 0xF8803208
Width 8 bits
Access Type rw
Reset Value 0x00000000
Description TPIU Test Pattern Repeat Counter Register
Field Name Bits Type Reset Value Description
PattCount 7:0 rw 0x0 8-bit counter value to indicate the number of
TRACECLKIN cycles that a pattern runs for
before switching to the next pattern.
Name FFSR
Relative Address 0x00000300
Absolute Address 0xF8803300
