Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1129
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register ITTRFLINACK Details
Register (tpiu) ITTRFLIN
Register ITTRFLIN Details
Register (tpiu) ITATBDATA0
Register ITATBDATA0 Details
Field Name Bits Type Reset Value Description
FLUSHINACK 1 wo 0x0 Set the value of FLUSHINACK
TRIGINACK 0 wo 0x0 Set the value of TRIGINACK
Name ITTRFLIN
Relative Address 0x00000EE8
Absolute Address 0xF8803EE8
Width 2 bits
Access Type ro
Reset Value x
Description Integration Test Trigger In and Flush In Register
Field Name Bits Type Reset Value Description
FLUSHIN 1 ro x Read the value of FLUSHIN
TRIGIN 0 ro x Read the value of TRIGIN
Name ITATBDATA0
Relative Address 0x00000EEC
Absolute Address 0xF8803EEC
Width 5 bits
Access Type ro
Reset Value x
Description Integration Test ATB Data Register 0
Field Name Bits Type Reset Value Description
ATDATA31 4 ro x Read the value of ATDATAS[31]
ATDATA23 3 ro x Read the value of ATDATAS[23]
ATDATA15 2 ro x Read the value of ATDATAS[15]
