Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1132
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register CTSR Details
Register (tpiu) CTCR
Register CTCR Details
Register (tpiu) LAR
Description Claim Tag Set Register
Field Name Bits Type Reset Value Description
3:0 rw 0xF The claim tag register is used for any
interrogating tools to determine if the device is
being programmed or has been programmed.
Read:
1= Claim tag is implemented, 0 = Claim tag is not
implemented
Write:
1= Set claim tag bit, 0= No effect
Name CTCR
Relative Address 0x00000FA4
Absolute Address 0xF8803FA4
Width 4 bits
Access Type rw
Reset Value 0x00000000
Description Claim Tag Clear Register
Field Name Bits Type Reset Value Description
3:0 rw 0x0 The claim tag register is used for any
interrogating tools to determine if the device is
being programmed or has been programmed.
Read: Current value of claim tag.
Write: 1= Clear claim tag bit, 0= No effect
Name LAR
Relative Address 0x00000FB0
Absolute Address 0xF8803FB0
Width 32 bits
Access Type wo
Reset Value 0x00000000
