Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1163
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (devcfg) XADCIF_MSTS
Register XADCIF_MSTS Details
Register (devcfg) XADCIF_CMDFIFO
M_DFIFO_GTH 8 rw 0x1 Interrupt mask Data FIFO level greater than
threshold interrupt.
M_OT 7 rw 0x1 Interrupt mask for over temperature alarm
interrupt
M_ALM 6:0 rw 0x7F Interrupt mask for alarm signals from XADC.
Name XADCIF_MSTS
Relative Address 0x0000010C
Absolute Address 0xF800710C
Width 32 bits
Access Type ro
Reset Value 0x00000500
Description XADC Interface miscellaneous Status Register : This register contains miscellaneous
status of the XADC Interface
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
reserved 31:20 ro 0x0 Reserved
CFIFO_LVL 19:16 ro 0x0 Command FIFO level.
DFIFO_LVL 15:12 ro 0x0 Data FIFO level.
CFIFOF 11 ro 0x0 Command FIFO full.
CFIFOE 10 ro 0x1 Command FIFO empty.
DFIFOF 9 ro 0x0 Data FIFO full.
DFIFOE 8 ro 0x1 Data FIFO empty.
OT 7 ro 0x0 Raw over temperature alarm from the XADC.
Latched version of the signal is available in the
interrupt status register.
ALM 6:0 ro 0x0 Raw alarm signals from the XADC.
Latched version of the signals are available in the
interrupt status register.
Name XADCIF_CMDFIFO
Relative Address 0x00000110
