Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1164
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register XADCIF_CMDFIFO Details
Register (devcfg) XADCIF_RDFIFO
Register XADCIF_RDFIFO Details
Register (devcfg) XADCIF_MCTL
Absolute Address 0xF8007110
Width 32 bits
Access Type wo
Reset Value 0x00000000
Description XADC Interface Command FIFO Register : This address is the entry point to the
command FIFO.
Commands get push into the FIFO when there is a write to this address
Field Name Bits Type Reset Value Description
CMD 31:0 wo 0x0 32-bit command.
Name XADCIF_RDFIFO
Relative Address 0x00000114
Absolute Address 0xF8007114
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description XADC Interface Data FIFO Register : This address is the exit point of the read data
FIFO.
Read data is returned when there is a read from this address
Field Name Bits Type Reset Value Description
RDDATA 31:0 ro 0x0 32-bit read data.
Name XADCIF_MCTL
Relative Address 0x00000118
Absolute Address 0xF8007118
Width 32 bits
Access Type rw
Reset Value 0x00000010
Description XADC Interface Miscellaneous Control Register : This register provides
miscellaneous control of the XADC Interface.
