Appendix B: Register Details
Register (dmac) FTR0
reserved 15:6 rud 0x0 read undefined
mgr_evnt_err 5 sro,ns
sraz,n
snsro
0x0 Indicates whether the DMA manager was
attempting to execute DMAWFE or DMASEV
with inappropriate security permissions:
0: the DMA manager has appropriate security to
execute DMAWFE or DMASEV
1: a DMA manager thread in the Non-secure state
attempted to execute either:
DMAWFE to wait for a secure event
H18DMASEV to create a secure event or secure
interrupt.
dmago_err 4 sro,ns
sraz,n
snsro
0x0 Indicates whether the DMA manager was
attempting to execute DMAGO with
inappropriate security permissions:
0: appropriate security to execute DMAGO
1: Non-secure state attempted to execute DMAGO
to create a DMA channel thread operating in the
Secure state
reserved 3:2 rud 0x0 read undefined
operand_invalid 1 sro,ns
sraz,n
snsro
0x0 Indicates whether the DMA manager was
attempting to execute an instruction operand that
was not valid for the configuration of the DMAC:
0: valid operand
1: invalid operand
undef_instr 0 sro,ns
sraz,n
snsro
0x0 Indicates whether the DMA manager was
attempting to execute an undefined instruction:
0: defined instruction
1: undefined instruction.
Name FTR0
Software Name FTC0
Relative Address 0x00000040
Absolute Address dmac0_ns: 0xF8004040
dmac0_s: 0xF8003040
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Default Type DMA Channel 0
Field Name Bits Type Reset Value Description
