Chapter 5: Interconnect
5.1.4 Clock Domains
The interconnect, masters, and slaves use the clocks shown inTable 5-2.:
Memory
interconnect
OCM
interconnect
AXI DDR_2x CPU_2x Async 64 - -
Central
interconnect
OCM
interconnect
AXI CPU_2x CPU_2x Sync 64 - -
L2 Cache
Slave
interconnect
AXI CPU_6x4x CPU_2x Sync 64 8, 8 -
Central
interconnect
Slave
interconnect
AXI CPU_2x CPU_2x Sync 64 - -
SCU
On-chip
RAM
AXI CPU_6x4x CPU_2x Sync 64 4, 4 -
OCM
interconnect
On-chip
RAM
AXI CPU_2x CPU_2x Sync 64 4, 4 -
Slave
interconnect
APB slaves APB CPU_2x CPU_1x Sync 32 1, 1 -
Slave
interconnect
AHB slaves AXI CPU_2x CPU_1x Sync 32 4, 4 -
Slave
interconnect
AXI_GP AXI CPU_2x MAXIGPnACLK Async 32 8, 8 -
L2 cache
DDR
controller
AXI CPU_6x4x DDR_3x Async 64 8, 8 X
Central
interconnect
DDR
controller
AXI CPU_2x DDR_3x Async 64 8, 8 -
Memory
interconnect
DDR
controller
AXI DDR_2x DDR_3x Async 64 8, 8 -
Slave
interconnect
GPV
(3)
CPU_2x (multiple) - - - -
Notes:
1. Each asynchronous path includes an asynchronous bridge for clock domain crossing.
2. Burst-length dependent (see AXI_HP Interfaces).
3. The path from the slave interconnect to GPV is an internal path within the entire interconnect structure. When accessing
GPV, ensure that all clocks are on.
Table 5-1: Interconnect Datapaths (Cont’d)
Source Destination Type
Clock
at source
Clock
at destination
Sync
or
Async
(1)
Data
width
R/W
Request
Capability
Advanced
QoS
Table 5-2: Clocks used by Interconnect, Masters, and Slaves
CPU_6x4x: CPUs, SCU, L2 Cache controller, On-Chip RAM
CPU_2x Central interconnect, master interconnect, slave interconnect, OCM interconnect
CPU_1x AHB masters, AHB slaves, APB slaves, DevC, DAP
DDR_3x DDR Memory Controller
DDR_2x Memory interconnect, FIFOs
