Chapter 5: Interconnect
Except for CPU_6X4X, CPU_2X, and CPU_1X, which are synchronous clocks with a ratio of 6:2:1 or
4:2:1, all clocks in Table 5-2 are asynchronous to one another, as shown in Figure 5-2.
SAXIACPACLK AXI_ACP slave port
SAXIHP0ACLK AXI_HP0 slave port
SAXIHP1ACLK AXI_HP1 slave port
SAXIHP2ACLK AXI_HP2 slave port
SAXIHP3ACLK AXI_HP3 slave port
SAXIGP0ACLK AXI_GP0 slave port
SAXIGP1ACLK AXI_GP1 slave port
MAXIGP0ACLK AXI_GP0 master port
MAXIGP1ACLK AXI_GP1 master port
Table 5-2: Clocks used by Interconnect, Masters, and Slaves (Cont’d)
CPU_6x4x: CPUs, SCU, L2 Cache controller, On-Chip RAM
