Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1242
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register SAR5 Details
Register (dmac) DAR5
Register DAR5 Details
Register (dmac) CCR5
Access Type mixed
Reset Value 0x00000000
Description Source Address DMA Channel 5
Field Name Bits Type Reset Value Description
src_addr 31:0 sro,ns
sraz,n
snsro
0x0 Source data address (physical memory address)
for DMA channel thread.
Name DAR5
Software Name XDmaPs_DA_n_OFFSET(5)
Relative Address 0x000004A4
Absolute Address dmac0_ns: 0xF80044A4
dmac0_s: 0xF80034A4
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Destination Addr DMA Channel 5
Field Name Bits Type Reset Value Description
dest_addr 31:0 sro,ns
sraz,n
snsro
0x0 Destination data address (physical memory
address) for DMA channel thread.
Name CCR5
Software Name XDmaPs_CC_n_OFFSET(5)
Relative Address 0x000004A8
Absolute Address dmac0_ns: 0xF80044A8
dmac0_s: 0xF80034A8
Width 32 bits
Access Type mixed
