Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1246
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (dmac) LC0_5
Register LC0_5 Details
Register (dmac) LC1_5
Name LC0_5
Software Name XDmaPs_LC0_n_OFFSET(5)
Relative Address 0x000004AC
Absolute Address dmac0_ns: 0xF80044AC
dmac0_s: 0xF80034AC
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Loop Counter 0 DMA Channel 5
Field Name Bits Type Reset Value Description
reserved 31:8 rud 0x0 reserved, read undefined
loop_counter_iteration 7:0 sro,ns
sraz,n
snsro
0x0 Provides the status of loop counter zero for the
DMA channel thread. The DMAC updates this
register when it executes DMALPEND[S|B], and
the DMA channel thread is programmed to use
loop counter zero.
Name LC1_5
Software Name XDmaPs_LC1_n_OFFSET(5)
Relative Address 0x000004B0
Absolute Address dmac0_ns: 0xF80044B0
dmac0_s: 0xF80034B0
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Loop Counter 1 DMA Channel 5
