Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1259
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register DBGINST0 Details
Register (dmac) DBGINST1
Description DMA Manager Instruction Part A
Field Name Bits Type Reset Value Description
instruction_byte1 31:24 swo,n
ssraz,
nsns
wo
0x0 instruction byte 1
instruction_byte0 23:16 swo,n
ssraz,
nsns
wo
0x0 instruction byte 0
reserved 15:11 waz 0x0 reserved, write as 0
channel_num 10:8 swo,n
ssraz,
nsns
wo
0x0 DMA channel number:
000: DMA channel 0
001: DMA channel 1
010: DMA channel 2
...
111: DMA channel 7
reserved 7:1 waz 0x0 reserved, write as 0
debug_thread 0 swo,n
ssraz,
nsns
wo
0x0 The debug thread encoding is as folLows:
0: DMA manager thread
1: DMA channel.
Note: When set to 1, the Channel number field
selects the DMA channel to debug.
Name DBGINST1
Relative Address 0x00000D0C
Absolute Address dmac0_ns: 0xF8004D0C
dmac0_s: 0xF8003D0C
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description DMA Manager Instruction Part B
