Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1272
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
excessive_collisns 0x00000140 32 ro 0x00000000 Excessive Collisions
late_collisns
0x00000144 32 ro 0x00000000 Late Collisions
deferred_tx_frames
0x00000148 32 ro 0x00000000 Deferred Transmission Frames
carrier_sense_errs
0x0000014C 32 ro 0x00000000 Carrier Sense Errors.
octets_rx_bot
0x00000150 32 ro 0x00000000 Octets Received [31:0]
octets_rx_top
0x00000154 32 ro 0x00000000 Octets Received [47:32]
frames_rx
0x00000158 32 ro 0x00000000 Frames Received
bdcast_fames_rx
0x0000015C 32 ro 0x00000000 Broadcast Frames Rx
multi_frames_rx
0x00000160 32 ro 0x00000000 Multicast Frames Rx
pause_rx
0x00000164 32 ro 0x00000000 Pause Frames Rx
frames_64b_rx
0x00000168 32 ro 0x00000000 Frames Rx, 64-byte length
frames_65to127b_rx
0x0000016C 32 ro 0x00000000 Frames Rx, 65 to 127-byte length
frames_128to255b_rx
0x00000170 32 ro 0x00000000 Frames Rx, 128 to 255-byte
length
frames_256to511b_rx
0x00000174 32 ro 0x00000000 Frames Rx, 256 to 511-byte
length
frames_512to1023b_rx
0x00000178 32 ro 0x00000000 Frames Rx, 512 to 1023-byte
length
frames_1024to1518b_rx
0x0000017C 32 ro 0x00000000 Frames Rx, 1024 to 1518-byte
length
undersz_rx
0x00000184 32 ro 0x00000000 Undersize frames received
oversz_rx
0x00000188 32 ro 0x00000000 Oversize frames received
jab_rx
0x0000018C 32 ro 0x00000000 Jabbers received
fcs_errors
0x00000190 32 ro 0x00000000 Frame check sequence errors
length_field_errors
0x00000194 32 ro 0x00000000 Length field frame errors
rx_symbol_errors
0x00000198 32 ro 0x00000000 Receive symbol errors
align_errors
0x0000019C 32 ro 0x00000000 Alignment errors
rx_resource_errors
0x000001A0 32 ro 0x00000000 Receive resource errors
rx_overrun_errors
0x000001A4 32 ro 0x00000000 Receive overrun errors
ip_hdr_csum_errors
0x000001A8 32 ro 0x00000000 IP header checksum errors
tcp_csum_errors
0x000001AC 32 ro 0x00000000 TCP checksum errors
udp_csum_errors
0x000001B0 32 ro 0x00000000 UDP checksum error
timer_strobe_s
0x000001C8 32 rw 0x00000000 1588 timer sync strobe seconds
timer_strobe_ns
0x000001CC 32 mixed 0x00000000 1588 timer sync strobe
nanoseconds
Register Name Address Width Type Reset Value Description
