Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1278
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
pause_en
(PAUSEEN)
13 rw 0x0 Pause enable - when set, transmission will pause
if a non zero 802.3 classic pause frame is received
and PFC has not been negotiated.
retry_test
(RETRYTESTEN)
12 rw 0x0 Retry test - must be set to zero for normal
operation.
If set to one the backoff between collisions will
always be one slot time. Setting this bit to one
helps test the too many retries condition. Also
used in the pause frame tests to reduce the pause
counter's decrement time from 512 bit times, to
every rx_clk cycle.
pcs_sel 11 rw 0x0 NA
0: GMII/MII interface enabled, TBI disabled
1: TBI enabled, GMII/MII disabled
gige_en
(1000)
10 rw 0x0 Gigabit mode enable - setting this bit configures
the GEM for 1000 Mbps operation.
0: 10/100 operation using MII or TBI interface
1: Gigabit operation using GMII or TBI interface
ext_addr_match_en
(EXTADDRMATCHEN
)
9 rw 0x0 External address match enable - when set the
external address match interface can be used to
copy frames to memory.
rx_1536_byte_frames
(1536RXEN)
8 rw 0x0 Receive 1536 byte frames - setting this bit means
the GEM will accept frames up to 1536 bytes in
length. Normally the GEM would reject any
frame above 1518 bytes.
uni_hash_en
(UCASTHASHEN)
7 rw 0x0 Unicast hash enable - when set, unicast frames
will be accepted when the 6 bit hash function of
the destination address points to a bit that is set in
the hash register.
multi_hash_en
(MCASTHASHEN)
6 rw 0x0 Multicast hash enable - when set, multicast
frames will be accepted when the 6 bit hash
function of the destination address points to a bit
that is set in the hash register.
no_broadcast
(BCASTDI)
5 rw 0x0 No broadcast - when set to logic one, frames
addressed to the broadcast address of all ones will
not be accepted.
copy_all
(COPYALLEN)
4 rw 0x0 Copy all frames - when set to logic one, all valid
frames will be accepted.
reserved 3 rw 0x0 Reserved. Do not modify.
disc_non_vlan
(NVLANDISC)
2 rw 0x0 Discard non-VLAN frames - when set only VLAN
tagged frames will be passed to the address
matching logic.
Field Name Bits Type Reset Value Description
