Appendix B: Register Details
Register (GEM) net_status
Register net_status Details
The network status register returns status information with respect to the PHY management interface.
full_duplex
(FDEN)
1 rw 0x0 Full duplex - if set to logic one, the transmit block
ignores the state of collision and carrier sense and
allows receive while transmitting. Also controls
the half-duplex pin.
speed
(100)
0 rw 0x0 Speed - set to logic one to indicate 100Mbps
operation, logic zero for 10Mbps. The value of this
pin is reflected on the speed_mode[0] output pin.
Name net_status
Software Name XEMACPS_NWSR
Relative Address 0x00000008
Absolute Address gem0: 0xE000B008
gem1: 0xE000C008
Width 32 bits
Access Type ro
Reset Value x
Description Network Status
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
reserved 31:7 ro 0x0 Reserved, read as zero, ignored on write.
pfc_pri_pause_neg 6 ro 0x0 Set when PFC Priority Based Pause has been
negotiated.
pcs_autoneg_pause_tx
_res
5ro0x0 NA
pcs_autoneg_pause_rx
_res
4ro0x0 NA
pcs_autoneg_dup_res 3 ro 0x0 NA
phy_mgmt_idle 2 ro 0x1 The PHY management logic is idle (i.e. has
completed).
mdio_in_pin_status
(MDIO)
1 ro x Returns status of the mdio_in pin
pcs_link_state 0 ro 0x0 NA
