Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1290
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
pdelay_req_rx
(XEMACPS_IXR_PTP
DRTX)
22 wo x Enable PTP pdelay_req frame received interrupt
sync_tx
(XEMACPS_IXR_PTPP
SRX)
21 wo x Enable PTP sync frame transmitted interrupt
delay_req_tx
(XEMACPS_IXR_PTPP
DRRX)
20 wo x Enable PTP delay_req frame transmitted
interrupt
sync_rx
(XEMACPS_IXR_PTPS
RX)
19 wo x Enable PTP sync frame received interrupt
delay_req_rx
(XEMACPS_IXR_PTP
DRRX)
18 wo x Enable PTP delay_req frame received interrupt
partner_pg_rx 17 wo x NA
autoneg_complete 16 wo x NA
ext_intr 15 wo x Enable external interrupt
pause_tx
(XEMACPS_IXR_PAU
SETX)
14 wo x Enable pause frame transmitted interrupt
pause_zero
(XEMACPS_IXR_PAU
SEZERO)
13 wo x Enable pause time zero interrupt
pause_nonzeroq
(XEMACPS_IXR_PAU
SENZERO)
12 wo x Enable pause frame with non-zero pause
quantum interrupt
hresp_not_ok
(XEMACPS_IXR_HRE
SPNOK)
11 wo x Enable hresp not OK interrupt
rx_overrun
(XEMACPS_IXR_RXO
VR)
10 wo x Enable receive overrun interrupt
link_chng 9 wo x Enable link change interrupt
reserved 8 wo x Not used
tx_complete
(XEMACPS_IXR_TXC
OMPL)
7 wo x Enable transmit complete interrupt
tx_corrupt_ahb_err
(XEMACPS_IXR_TXEX
H)
6 wo x Enable transmit frame corruption due to AHB
error interrupt
Field Name Bits Type Reset Value Description
