Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1292
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Field Name Bits Type Reset Value Description
reserved 31:27 wo x Reserved
tsu_sec_incr 26 wo x Disable TSU seconds register increment interrupt
pdelay_resp_tx
(XEMACPS_IXR_PTPP
STX)
25 wo x Disable PTP pdelay_resp frame transmitted
interrupt
pdelay_req_tx
(XEMACPS_IXR_PTPP
DRTX)
24 wo x Disable PTP pdelay_req frame transmitted
interrupt
pdelay_resp_rx
(XEMACPS_IXR_PTPS
TX)
23 wo x Disable PTP pdelay_resp frame received interrupt
pdelay_req_rx
(XEMACPS_IXR_PTP
DRTX)
22 wo x Disable PTP pdelay_req frame received interrupt
sync_tx
(XEMACPS_IXR_PTPP
SRX)
21 wo x Disable PTP sync frame transmitted interrupt
delay_req_tx
(XEMACPS_IXR_PTPP
DRRX)
20 wo x Disable PTP delay_req frame transmitted
interrupt
sync_rx
(XEMACPS_IXR_PTPS
RX)
19 wo x Disable PTP sync frame received interrupt
delay_req_rx
(XEMACPS_IXR_PTP
DRRX)
18 wo x Disable PTP delay_req frame received interrupt
partner_pg_rx 17 wo x NA
autoneg_complete 16 wo x NA
ext_intr 15 wo x Disable external interrupt
pause_tx
(XEMACPS_IXR_PAU
SETX)
14 wo x Disable pause frame transmitted interrupt
pause_zero
(XEMACPS_IXR_PAU
SEZERO)
13 wo x Disable pause time zero interrupt
pause_nonzeroq
(XEMACPS_IXR_PAU
SENZERO)
12 wo x Disable pause frame with non-zero pause
quantum interrupt
hresp_not_ok
(XEMACPS_IXR_HRE
SPNOK)
11 wo x Disable hresp not OK interrupt
