Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1301
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (GEM) spec_addr3_bot
Register spec_addr3_bot Details
Register (GEM) spec_addr3_top
Register spec_addr3_top Details
Name spec_addr3_bot
Software Name XEMACPS_LADDR3L
Relative Address 0x00000098
Absolute Address gem0: 0xE000B098
gem1: 0xE000C098
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Specific Address 3 Bottom [31:0]
Field Name Bits Type Reset Value Description
31:0 rw 0x0 Least significant 32 bits of the destination address,
that is bits 31:0. Bit zero indicates whether the
address is multicast or unicast and corresponds to
the least significant bit of the first byte received.
Name spec_addr3_top
Software Name XEMACPS_LADDR3H
Relative Address 0x0000009C
Absolute Address gem0: 0xE000B09C
gem1: 0xE000C09C
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Specific Address 3 Top [47:32]
Field Name Bits Type Reset Value Description
reserved 31:16 ro 0x0 Reserved, read as 0, ignored on write
addr_msbs 15:0 rw 0x0 Specific address 3. The most significant bits of the
destination address, that is bits 47:32.
