Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1303
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (GEM) type_id_match1
Register type_id_match1 Details
Register (GEM) type_id_match2
Register type_id_match2 Details
Name type_id_match1
Software Name XEMACPS_MATCH1
Relative Address 0x000000A8
Absolute Address gem0: 0xE000B0A8
gem1: 0xE000C0A8
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Type ID Match 1
Field Name Bits Type Reset Value Description
copy_en 31 rw 0x0 Enable copying of type ID match 1 matched
frames
reserved 30:16 ro 0x0 Reserved, read as 0, ignored on write
type_id_match1 15:0 rw 0x0 Type ID match 1. For use in comparisons with
received frames type ID/length field.
Name type_id_match2
Software Name XEMACPS_MATCH2
Relative Address 0x000000AC
Absolute Address gem0: 0xE000B0AC
gem1: 0xE000C0AC
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Type ID Match 2
Field Name Bits Type Reset Value Description
copy_en 31 rw 0x0 Enable copying of type ID match 2 matched
frames
