Appendix B: Register Details
Register (GEM) type_id_match3
Register type_id_match3 Details
Register (GEM) type_id_match4
reserved 30:16 ro 0x0 Reserved, read as 0, ignored on write
type_id_match2 15:0 rw 0x0 Type ID match 2. For use in comparisons with
received frames type ID/length field.
Name type_id_match3
Software Name XEMACPS_MATCH3
Relative Address 0x000000B0
Absolute Address gem0: 0xE000B0B0
gem1: 0xE000C0B0
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Type ID Match 3
Field Name Bits Type Reset Value Description
Field Name Bits Type Reset Value Description
copy_en 31 rw 0x0 Enable copying of type ID match 3 matched
frames
reserved 30:16 ro 0x0 Reserved, read as 0, ignored on write
type_id_match3 15:0 rw 0x0 Type ID match 3. For use in comparisons with
received frames type ID/length field.
Name type_id_match4
Software Name XEMACPS_MATCH4
Relative Address 0x000000B4
Absolute Address gem0: 0xE000B0B4
gem1: 0xE000C0B4
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Type ID Match 4
