Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1305
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register type_id_match4 Details
Register (GEM) wake_on_lan
Register wake_on_lan Details
Field Name Bits Type Reset Value Description
copy_en 31 rw 0x0 Enable copying of type ID match 4 matched
frames
reserved 30:16 ro 0x0 Reserved, read as 0, ignored on write
type_id_match4 15:0 rw 0x0 Type ID match 4. For use in comparisons with
received frames type ID/length field.
Name wake_on_lan
Relative Address 0x000000B8
Absolute Address gem0: 0xE000B0B8
gem1: 0xE000C0B8
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Wake on LAN Register
Field Name Bits Type Reset Value Description
reserved 31:20 ro 0x0 Reserved - read 0, ignored when written
multi_hash_en 19 rw 0x0 Wake on LAN multicast hash event enable. When
set multicast hash events will cause the wol
output to be asserted.
spec_addr_reg1_en 18 rw 0x0 Wake on LAN specific address register 1 event
enable. When set specific address 1 events will
cause the wol output to be asserted.
arp_req_en 17 rw 0x0 Wake on LAN ARP request event enable. When
set ARP request events will cause the wol output
to be asserted.
magic_pkt_en 16 rw 0x0 Wake on LAN magic packet event enable. When
set magic packet events will cause the wol output
to be asserted.
arp_req_ip_addr 15:0 rw 0x0 Wake on LAN ARP request IP address. Written to
define the least significant 16 bits of the target IP
address that is matched to generate a Wake on
LAN event. A value of zero will not generate an
event, even if this is matched by the received
frame.
