Appendix B: Register Details
Register (GEM) ipg_stretch
Register ipg_stretch Details
Register (GEM) stacked_vlan
Register stacked_vlan Details
Name ipg_stretch
Software Name XEMACPS_STRETCH
Relative Address 0x000000BC
Absolute Address gem0: 0xE000B0BC
gem1: 0xE000C0BC
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description IPG stretch register
Field Name Bits Type Reset Value Description
reserved 31:16 ro 0x0 Reserved, read as 0, ignored on write.
ipg_stretch 15:0 rw 0x0 Bits 7:0 are multiplied with the previously
transmitted frame length (including preamble)
bits 15:8 +1 divide the frame length. If the
resulting number is greater than 96 and bit 28 is
set in the network configuration register then the
resulting number is used for the transmit
inter-packet-gap. 1 is added to bits 15:8 to prevent
a divide by zero.
Name stacked_vlan
Relative Address 0x000000C0
Absolute Address gem0: 0xE000B0C0
gem1: 0xE000C0C0
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Stacked VLAN Register
Field Name Bits Type Reset Value Description
stacked_vlan_en 31 rw 0x0 Enable Stacked VLAN processing mode
