Appendix B: Register Details
Register frames_tx Details
Statistical counter for Frames transmitted without an error and exclude pause frames.
NOTES for ALL Statistical registers for Frames Transferred:
The a statistical counter is read by software, it is cleared to zero by the hardware. When a counter reaches
its maximum value, it stops counting and is read with all 1s. The statistical counters must be read
frequently enough if data loss is to be prevented.
For test purposes, all of the statistical counters may be written to (not just read) by setting bit 7
(wren_stat_regs) in the network control register. Also for test purposes, all of the statistical counters can be
incremented (by one) by writing a 1 to bit 6 (incr_stat_regs) of the network control register.
Register (GEM) broadcast_frames_tx
Register broadcast_frames_tx Details
Statistical counter for Broadcast Frames transmitted without an error and exclude pause frames. Refer to
the FRAMES_TX register for additional information.
Register (GEM) multi_frames_tx
Field Name Bits Type Reset Value Description
31:0 ro 0x0 Frames transmitted without error. A 32 bit
register counting the number of frames
successfully transmitted, i.e., no under run and
not too many retries. Excludes pause frames.
Name broadcast_frames_tx
Software Name XEMACPS_TXBCCNT
Relative Address 0x0000010C
Absolute Address gem0: 0xE000B10C
gem1: 0xE000C10C
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Broadcast frames Tx
Field Name Bits Type Reset Value Description
31:0 ro 0x0 Broadcast frames transmitted without error. A 32
bit register counting the number of broadcast
frames successfully transmitted without error, i.e.,
no under run and not too many retries. Excludes
pause frames.
Name multi_frames_tx
