Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1312
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register multi_frames_tx Details
Statistical counter for Multicast Frames transmitted without an error and exclude pause frames. Refer to
the FRAMES_TX register for additional information.
Register (GEM) pause_frames_tx
Register pause_frames_tx Details
Statistical counter for Pause Frames transmitted without an error and not sent through the FIFO interface.
Refer to the FRAMES_TX register for additional information.
Software Name XEMACPS_TXMCCNT
Relative Address 0x00000110
Absolute Address gem0: 0xE000B110
gem1: 0xE000C110
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Multicast frames Tx
Field Name Bits Type Reset Value Description
31:0 ro 0x0 Multicast frames transmitted without error. A 32
bit register counting the number of multicast
frames successfully transmitted without error, i.e.,
no under run and not too many retries. Excludes
pause frames.
Name pause_frames_tx
Software Name XEMACPS_TXPAUSECNT
Relative Address 0x00000114
Absolute Address gem0: 0xE000B114
gem1: 0xE000C114
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Pause frames Tx
