Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1313
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (GEM) frames_64b_tx
Register frames_64b_tx Details
Statistical counter of frames of 64 bytes that are transmitted without error. Does not include pause frames.
Refer to the FRAMES_TX register for additional information.
Register (GEM) frames_65to127b_tx
Field Name Bits Type Reset Value Description
reserved 31:16 ro 0x0 Reserved, read as 0, ignored on write.
pause_frames_tx 15:0 ro 0x0 Transmitted pause frames - a 16 bit register
counting the number of pause frames
transmitted. Only pause frames triggered by the
register interface or through the external pause
pins are counted as pause frames. Pause frames
received through the external FIFO interface are
counted in the frames transmitted counter.
Name frames_64b_tx
Software Name XEMACPS_TX64CNT
Relative Address 0x00000118
Absolute Address gem0: 0xE000B118
gem1: 0xE000C118
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Frames Tx, 64-byte length
Field Name Bits Type Reset Value Description
31:0 ro 0x0 64 byte frames transmitted without error. A 32 bit
register counting the number of 64 byte frames
successfully transmitted without error, i.e., no
under run and not too many retries. Excludes
pause frames.
Name frames_65to127b_tx
Software Name XEMACPS_TX65CNT
Relative Address 0x0000011C
Absolute Address gem0: 0xE000B11C
gem1: 0xE000C11C
Width 32 bits
