Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1314
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register frames_65to127b_tx Deta ils
Statistical counter of frames of 65 to 127 bytes that are transmitted without error. Does not include pause
frames. Refer to the FRAMES_TX register for additional information.
Register (GEM) frames_128to255b_tx
Register frames_128to255b_tx Details
Statistical counter of frames of 128 to 255 bytes that are transmitted without error. Does not include pause
frames. Refer to the FRAMES_TX register for additional information.
Register (GEM) frames_256to511b_tx
Access Type ro
Reset Value 0x00000000
Description Frames Tx, 65 to 127-byte length
Field Name Bits Type Reset Value Description
31:0 ro 0x0 65 to127 byte frames transmitted without error. A
32 bit register counting the number of 65 to127
byte frames successfully transmitted without
error, i.e., no under run and not too many retries.
Name frames_128to255b_tx
Software Name XEMACPS_TX128CNT
Relative Address 0x00000120
Absolute Address gem0: 0xE000B120
gem1: 0xE000C120
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Frames Tx, 128 to 255-byte length
Field Name Bits Type Reset Value Description
31:0 ro 0x0 128 to 255 byte frames transmitted without error.
A 32 bit register counting the number of 128 to 255
byte frames successfully transmitted without
error, i.e., no under run and not too many retries.
Name frames_256to511b_tx
Software Name XEMACPS_TX256CNT
Relative Address 0x00000124
