Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1316
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (GEM) frames_1024to1518b_tx
Register frames_1024to1518b_tx Details
Statistical counter of frames of1024 to 1518 bytes that are transmitted without error. Does not include pause
frames. Refer to the FRAMES_TX register for additional information.
Register (GEM) tx_under_runs
Register tx_under_runs Details
In statistics register block. Is reset to zero on a read and stick at all ones when it counts to its maximum
value. It should be read frequently enough to prevent loss of data.
For test purposes, it may be written by setting bit 7 (Write Enable) in the network control register. Setting
bit 6 (increment statistics) in the network control register causes all the statistics registers to increment by
one, again for test purposes.
Name frames_1024to1518b_tx
Software Name XEMACPS_TX1024CNT
Relative Address 0x0000012C
Absolute Address gem0: 0xE000B12C
gem1: 0xE000C12C
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Frame Tx, 1024 to 1518-byte length
Field Name Bits Type Reset Value Description
31:0 ro 0x0 1024 to 1518 byte frames transmitted without
error. A 32 bit register counting the number of
1024 to 1518 byte frames successfully transmitted
without error, i.e., no under run and not too many
retries.
Name tx_under_runs
Software Name XEMACPS_TXURUNCNT
Relative Address 0x00000134
Absolute Address gem0: 0xE000B134
gem1: 0xE000C134
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Transmit under runs
