Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1320
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register deferred_tx_frames Details
In statistics register block. Is reset to zero on a read and stick at all ones when it counts to its maximum
value. It should be read frequently enough to prevent loss of data.
For test purposes, it may be written by setting bit 7 (Write Enable) in the network control register. Setting
bit 6 (increment statistics) in the network control register causes all the statistics registers to increment by
one, again for test purposes.
Once a statistics register has been read, it is automatically cleared.
Register (GEM) carrier_sense_errs
Register carrier_sense_errs Details
In statistics register block. Is reset to zero on a read and sticks at all ones when it counts to its maximum
value. It should be read frequently enough to prevent loss of data.
Relative Address 0x00000148
Absolute Address gem0: 0xE000B148
gem1: 0xE000C148
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Deferred Transmission Frames
Field Name Bits Type Reset Value Description
reserved 31:18 ro 0x0 Reserved, read as 0, ignored on write.
deferred_tx 17:0 ro 0x0 Deferred transmission frames - an 18 bit register
counting the number of frames experiencing
deferral due to carrier sense being active on their
first attempt at transmission. Frames involved in
any collision are not counted nor are frames that
experienced a transmit under run.
Name carrier_sense_errs
Software Name XEMACPS_TXCSENSECNT
Relative Address 0x0000014C
Absolute Address gem0: 0xE000B14C
gem1: 0xE000C14C
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Carrier Sense Errors.
