Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1324
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (GEM) multi_frames_rx
Register multi_frames_rx Details
Statistical counter for Multicast Frames received without an error and exclude pause frames. Refer to the
FRAMES_RX register for additional information.
Register (GEM) pause_rx
Field Name Bits Type Reset Value Description
31:0 ro 0x0 Broadcast frames received without error. A 32 bit
register counting the number of broadcast frames
successfully received without error. Excludes
pause frames, and is only incremented if the
frame is successfully filtered and copied to
memory.
Name multi_frames_rx
Software Name XEMACPS_RXMULTICNT
Relative Address 0x00000160
Absolute Address gem0: 0xE000B160
gem1: 0xE000C160
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Multicast Frames Rx
Field Name Bits Type Reset Value Description
31:0 ro 0x0 Multicast frames received without error. A 32 bit
register counting the number of multicast frames
successfully received without error. Excludes
pause frames, and is only incremented if the
frame is successfully filtered and copied to
memory.
Name pause_rx
Software Name XEMACPS_RXPAUSECNT
Relative Address 0x00000164
Absolute Address gem0: 0xE000B164
gem1: 0xE000C164
Width 32 bits
Access Type ro
