Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1328
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (GEM) frames_1024to1518b_rx
Register frames_1024to1518b_rx Details
Statistical counter for frames of 1024 to 1518 bytes in length that are received without an error and exclude
pause frames. Refer to the FRAMES_RX register for additional information.
Register (GEM) undersz_rx
Field Name Bits Type Reset Value Description
31:0 ro 0x0 512 to 1023 byte frames received without error. A
32 bit register counting the number of 512 to 1023
byte frames successfully received without error.
Excludes pause frames, and is only incremented if
the frame is successfully filtered and copied to
memory.
Name frames_1024to1518b_rx
Software Name XEMACPS_RX1024CNT
Relative Address 0x0000017C
Absolute Address gem0: 0xE000B17C
gem1: 0xE000C17C
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Frames Rx, 1024 to 1518-byte length
Field Name Bits Type Reset Value Description
31:0 ro 0x0 1024 to 1518 byte frames received without error. A
32 bit register counting the number of 1024 to 1518
byte frames successfully received without error.
Excludes pause frames, and is only incremented if
the frame is successfully filtered and copied to
memory.
Name undersz_rx
Software Name XEMACPS_RXUNDRCNT
Relative Address 0x00000184
Absolute Address gem0: 0xE000B184
gem1: 0xE000C184
Width 32 bits
Access Type ro
