Appendix B: Register Details
Register (GEM) length_field_errors
Register length_field_errors Details
Register (GEM) rx_symbol_errors
Name length_field_errors
Software Name XEMACPS_RXLENGTHCNT
Relative Address 0x00000194
Absolute Address gem0: 0xE000B194
gem1: 0xE000C194
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Length field frame errors
Field Name Bits Type Reset Value Description
reserved 31:10 ro 0x0 Reserved, read as 0, ignored on write.
length_field_errors 9:0 ro 0x0 Length field frame errors - this 10-bit register
counts the number of frames received that have a
measured length shorter than that extracted from
the length field (bytes 13 and 14). This condition is
only counted if the value of the length field is less
than 0x0600, the frame is not of excessive length
and checking is enabled through bit 16 of the
network configuration register.
Name rx_symbol_errors
Software Name XEMACPS_RXSYMBCNT
Relative Address 0x00000198
Absolute Address gem0: 0xE000B198
gem1: 0xE000C198
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Receive symbol errors
