Appendix B: Register Details
Register timer_ns Details
Register (GEM) timer_adjust
Register timer_adjust Details
Absolute Address gem0: 0xE000B1D4
gem1: 0xE000C1D4
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description 1588 timer nanoseconds
Field Name Bits Type Reset Value Description
reserved 31:30 ro 0x0 Reserved, read as 0, ignored on write.
timer_ct_ns 29:0 rw 0x0 Timer count in nanoseconds. This register is
writeable. It can also be adjusted by writes to the
1588 timer adjust register. It increments by the
value of the 1588 timer increment register each
clock cycle.
Name timer_adjust
Software Name XEMACPS_1588_ADJ
Relative Address 0x000001D8
Absolute Address gem0: 0xE000B1D8
gem1: 0xE000C1D8
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description 1588 timer adjust
Field Name Bits Type Reset Value Description
add_subn 31 wo 0x0 Write as one to subtract from the 1588 timer. Write
as zero to add to it.
reserved 30 ro 0x0 Reserved, read as 0, ignored on write.
ns_delta 29:0 wo 0x0 The number of nanoseconds to increment or
decrement the 1588 timer nanoseconds register. If
necessary, the 1588 seconds register will be
incremented or decremented.
