Appendix B: Register Details
Register ptp_rx_s Details
Register (GEM) ptp_rx_ns
Register ptp_rx_ns Details
Register (GEM) ptp_peer_tx_s
Access Type ro
Reset Value 0x00000000
Description PTP event frame received seconds
Field Name Bits Type Reset Value Description
31:0 ro 0x0 The register is updated with the value that the
1588 timer seconds register held when the SFD of
a PTP receive primary event crosses the MII
interface. The actual update occurs when the
GEM recognizes the frame as a PTP sync or
delay_req frame. An interrupt is issued when the
register is updated.
Name ptp_rx_ns
Software Name XEMACPS_PTP_RXNANOSEC
Relative Address 0x000001EC
Absolute Address gem0: 0xE000B1EC
gem1: 0xE000C1EC
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description PTP event frame received nanoseconds.
Field Name Bits Type Reset Value Description
reserved 31:30 ro 0x0 Reserved, read as 0, ignored on write.
ns_reg_val 29:0 ro 0x0 The register is updated with the value that the
1588 timer nanoseconds register held when the
SFD of a PTP receive primary event crosses the
MII interface. The actual update occurs when the
GEM recognizes the frame as a PTP sync or
delay_req frame. An interrupt is issued when the
register is updated.
Name ptp_peer_tx_s
Software Name XEMACPS_PTPP_TXSEC
