Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1359
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (gpio) INT_MASK_0
Register INT_MASK_0 Details
This register shows which bits are currently masked and which are un-masked/enabled. This register is
read only, so masks cannot be changed here. Use INT_EN and INT_DIS to change the mask value.
This register controls bank0, which corresponds to MIO[31:0].
Register (gpio) INT_EN_0
Field Name Bits Type Reset Value Description
OP_ENABLE_0 31:0 rw 0x0 Output enables
0: disabled
1: enabled
Each bit configures the corresponding pin within
the 32-bit bank
Name INT_MASK_0
Software Name INTMASK
Relative Address 0x0000020C
Absolute Address 0xE000A20C
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Interrupt Mask Status (GPIO Bank0, MIO)
Field Name Bits Type Reset Value Description
INT_MASK_0 31:0 ro 0x0 Interrupt mask
0: interrupt source enabled
1: interrupt source masked
Each bit reports the status for the corresponding
pin within the 32-bit bank
Name INT_EN_0
Software Name INTEN
Relative Address 0x00000210
Absolute Address 0xE000A210
Width 32 bits
Access Type wo
Reset Value 0x00000000
