Appendix B: Register Details
Register OEN_1 Details
This register operates in exactly the same manner as OEN_0, except that it reflects bank1, which
corresponds to MIO[53:32].
Register (gpio) INT_MASK_1
Register INT_MASK_1 Details
This register operates in exactly the same manner as INT_MASK_0, except that it reflects bank1, which
corresponds to MIO[53:32].
Register (gpio) INT_EN_1
Register INT_EN_1 Details
This register operates in exactly the same manner as INT_EN_0, except that it reflects bank1, which
corresponds to MIO[53:32].
Description Output enable (GPIO Bank1, MIO)
Field Name Bits Type Reset Value Description
OP_ENABLE_1 21:0 rw 0x0 Operation is the same as OEN_0[OP_ENABLE_0]
Name INT_MASK_1
Relative Address 0x0000024C
Absolute Address 0xE000A24C
Width 22 bits
Access Type ro
Reset Value 0x00000000
Description Interrupt Mask Status (GPIO Bank1, MIO)
Field Name Bits Type Reset Value Description
INT_MASK_1 21:0 ro 0x0 Operation is the same as
INT_MASK_0[INT_MASK_0]
Name INT_EN_1
Relative Address 0x00000250
Absolute Address 0xE000A250
Width 22 bits
Access Type wo
Reset Value 0x00000000
Description Interrupt Enable/Unmask (GPIO Bank1, MIO)
