Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1366
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register (gpio) INT_TYPE_1
Register INT_TYPE_1 Details
This register operates in exactly the same manner as INT_TYPE_0, except that it reflects bank1, which
corresponds to MIO[53:32].
Register (gpio) INT_POLARITY_1
Register INT_POLARITY_1 Details
This register operates in exactly the same manner as INT_POLARITY_0, except that it reflects bank1, which
corresponds to MIO[53:32].
Register (gpio) INT_ANY_1
Name INT_TYPE_1
Relative Address 0x0000025C
Absolute Address 0xE000A25C
Width 22 bits
Access Type rw
Reset Value 0x003FFFFF
Description Interrupt Type (GPIO Bank1, MIO)
Field Name Bits Type Reset Value Description
INT_TYPE_1 21:0 rw 0x3FFFFF Operation is the same as
INT_TYPE_0[INT_TYPE_0]
Name INT_POLARITY_1
Relative Address 0x00000260
Absolute Address 0xE000A260
Width 22 bits
Access Type rw
Reset Value 0x00000000
Description Interrupt Polarity (GPIO Bank1, MIO)
Field Name Bits Type Reset Value Description
INT_POL_1 21:0 rw 0x0 Operation is the same as
INT_POLARITY_0[INT_POL_0]
Name INT_ANY_1
Relative Address 0x00000264
