Appendix B: Register Details
Register (gpio) INT_TYPE_2
Register INT_TYPE_2 Details
This register operates in exactly the same manner as INT_TYPE_0, except that it reflects bank2, which
corresponds to EMIO[31:0].
Register (gpio) INT_POLARITY_2
Register INT_POLARITY_2 Details
This register operates in exactly the same manner as INT_POLARITY_0, except that it reflects bank2, which
corresponds to EMIO[31:0].
Register (gpio) INT_ANY_2
Name INT_TYPE_2
Relative Address 0x0000029C
Absolute Address 0xE000A29C
Width 32 bits
Access Type rw
Reset Value 0xFFFFFFFF
Description Interrupt Type (GPIO Bank2, EMIO)
Field Name Bits Type Reset Value Description
INT_TYPE_2 31:0 rw 0xFFFFFFFF Operation is the same as
INT_TYPE_0[INT_TYPE_0]
Name INT_POLARITY_2
Relative Address 0x000002A0
Absolute Address 0xE000A2A0
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Interrupt Polarity (GPIO Bank2, EMIO)
Field Name Bits Type Reset Value Description
INT_POL_2 31:0 rw 0x0 Operation is the same as
INT_POLARITY_0[INT_POL_0]
Name INT_ANY_2
Relative Address 0x000002A4
