Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1372
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register OEN_3 Details
This register operates in exactly the same manner as OEN_0, except that it reflects bank3, which
corresponds to EMIO[63:32].
Register (gpio) INT_MASK_3
Register INT_MASK_3 Details
This register operates in exactly the same manner as INT_MASK_0, except that it reflects bank3, which
corresponds to EMIO[63:32].
Register (gpio) INT_EN_3
Register INT_EN_3 Details
This register operates in exactly the same manner as INT_EN_0, except that it reflects bank3, which
corresponds to EMIO[63:32].
Description Output enable (GPIO Bank3, EMIO)
Field Name Bits Type Reset Value Description
OP_ENABLE_3 31:0 rw 0x0 Operation is the same as OEN_0[OP_ENABLE_0]
Name INT_MASK_3
Relative Address 0x000002CC
Absolute Address 0xE000A2CC
Width 32 bits
Access Type ro
Reset Value 0x00000000
Description Interrupt Mask Status (GPIO Bank3, EMIO)
Field Name Bits Type Reset Value Description
INT_MASK_3 31:0 ro 0x0 Operation is the same as
INT_MASK_0[INT_MASK_0]
Name INT_EN_3
Relative Address 0x000002D0
Absolute Address 0xE000A2D0
Width 32 bits
Access Type wo
Reset Value 0x00000000
Description Interrupt Enable/Unmask (GPIO Bank3, EMIO)
