Appendix B: Register Details
Register I2C_address_reg0 Details
Register (IIC) I2C_data_reg0
Register I2C_data_reg0 Details
Register (IIC) Interrupt_status_reg0
Access Type mixed
Reset Value 0x00000000
Description IIC Address register
Field Name Bits Type Reset Value Description
reserved 15:10 ro 0x0 Reserved, read as zero, ignored on write.
ADD
(MASK)
9:0 rw 0x0 Address
0 - 1024: Normal addressing mode uses add[6:0].
Extended addressing mode uses add[9:0].
Name I2C_data_reg0
Software Name DATA
Relative Address 0x0000000C
Absolute Address i2c0: 0xE000400C
i2c1: 0xE000500C
Width 16 bits
Access Type mixed
Reset Value 0x00000000
Description IIC data register
Field Name Bits Type Reset Value Description
reserved 15:8 ro 0x0
DATA
(MASK)
7:0 rw 0x0 data
0 -255: When written to, the data register sets data
to transmit. When read from, the data register
reads the last received byte of data.
Name Interrupt_status_reg0
Software Name ISR
Relative Address 0x00000010
Absolute Address i2c0: 0xE0004010
i2c1: 0xE0005010
