Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 139
UG585 (v1.11) September 27, 2016
Chapter 5: Interconnect
Table 5-9: AXI Signals Summary
AXI Channel
AXI PS Masters AXI PS Slaves
M_AXI_GP{0,1} I/O
S_AXI_GP{0,1}
S_AXI_HP{0:3}
S_AXI_ACP
I/O
Clock, Reset
MAXIGP{0,1}ACLK I SAXIGP{0,1}ACLK
SAXIHP{0:3}ACLK
SAXIACPACLK
I
MAXIGP{0,1}ARESETN O SAXIGP{0,1}ARESETN
SAXIHP{0:3}ARESETN
SAXIACPARESETN
O
Read Address
MAXIGP{0,1}ARADDR[31:0] O SAXIGP{0,1}ARADDR[31:0]
SAXIHP{0:3}ARADDR[31:0]
SAXIACPARADDR[31:0]
I
MAXIGP{0,1}ARVALID O SAXIGP{0,1}ARVALID
SAXIHP{0:3}ARVALID
SAXIACPARVALID
I
MAXIGP{0,1}ARREADY I SAXIGP{0,1}ARREADY
SAXIHP{0:3}ARREADY
SAXIACPARREADY
O
MAXIGP{0,1}ARID[11:0] O SAXIGP{0,1}ARID[5:0]
SAXIHP{0:3}ARID[5:0]
SAXIACPARID[2:0]
I
MAXIGP{0,1}ARLOCK[1:0] O SAXIGP{0,1}ARLOCK[1:0]
SAXIHP{0:3}ARLOCK[1:0]
SAXIACPARLOCK[1:0]
I
MAXIGP{0,1}ARCACHE[3:0] O SAXIGP{0,1}ARCACHE[3:0]
SAXIHP{0:3}ARCACHE[3:0]
SAXIACPARCACHE[3:0]
I
MAXIGP{0,1}ARPROT[2:0] O SAXIGP{0,1}ARPROT[2:0]
SAXIHP{0:3}ARPROT[2:0]
SAXIACPARPROT[2:0]
I
MAXIGP{0,1}ARLEN[3:0] O SAXIGP{0,1}ARLEN[3:0]
SAXIHP{0:3}ARLEN[3:0]
SAXIACPARLEN[3:0]
I
MAXIGP{0,1}ARSIZE[1:0] O SAXIGP{0,1}ARSIZE[1:0]
SAXIHP{0:3}ARSIZE[2:0]
SAXIACPARSIZE[2:0]
I
MAXIGP{0,1}ARBURST[1:0] O SAXIGP{0,1}ARBURST[1:0]
SAXIHP{0:3}ARBURST[1:0]
SAXIACPARBURST[1:0]
I
MAXIGP{0,1}ARQOS[3:0] O SAXIGP{0,1}ARQOS[3:0]
SAXIHP{0:3}ARQOS[3:0]
SAXIACPARQOS[3:0]
I
