Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1390
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register Slave_mon_pause_reg0 Details
Register (IIC) Time_out_reg0
Register Time_out_reg0 Details
Register (IIC) Intrpt_mask_reg0
Field Name Bits Type Reset Value Description
reserved 7:4 ro 0x0 Reserved, read as zero, ignored on write.
Pause
(MASK)
3:0 rw 0x0 pause interval
0 - 7: pause interval
Name Time_out_reg0
Software Name TIME_OUT
Relative Address 0x0000001C
Absolute Address i2c0: 0xE000401C
i2c1: 0xE000501C
Width 8 bits
Access Type rw
Reset Value 0x0000001F
Description Time out register
Field Name Bits Type Reset Value Description
TO
(MASK)
7:0 rw 0x1F Time Out
255 - 31 : value of time out register
Name Intrpt_mask_reg0
Software Name IMR
Relative Address 0x00000020
Absolute Address i2c0: 0xE0004020
i2c1: 0xE0005020
Width 16 bits
Access Type ro
Reset Value 0x000002FF
Description Interrupt mask register
