Appendix B: Register Details
Register (L2Cpl310) reg1_data_ram_control
Register reg1_data_ram_control Details
Name reg1_data_ram_control
Relative Address 0x0000010C
Absolute Address 0xF8F0210C
Width 32 bits
Access Type mixed
Reset Value 0x00000777
Description configures data RAM latencies
Field Name Bits Type Reset Value Description
reserved 31:11 waz,r
az
0x0 reserved, reserved
ram_wr_access_lat 10:8 rw 0x7 RAM write access latency Default value depends
on the value of pl310_DATA_WRITE_LAT
b000 = 1 cycle of latency, there is no additional
latency.
b001 = 2 cycles of latency.
b010 = 3 cycles of latency.
b011 = 4 cycles of latency.
b100 = 5 cycles of latency.
b101 = 6 cycles of latency.
b110 = 7 cycles of latency.
b111 = 8 cycles of latency
reserved 7 waz,r
az
0x0 reserved, reserved
ram_rd_access_lat 6:4 rw 0x7 RAM read access latency Default value depends
on the value of pl310_DATA_READ_LAT
b000 = 1 cycle of latency, there is no additional
latency.
b001 = 2 cycles of latency.
b010 = 3 cycles of latency.
b011 = 4 cycles of latency.
b100 = 5 cycles of latency.
b101 = 6 cycles of latency.
b110 = 7 cycles of latency.
b111 = 8 cycles of latency.
