Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 141
UG585 (v1.11) September 27, 2016
Chapter 5: Interconnect
MAXIGP{0,1}AWREADY I SAXIGP{0,1}AWREADY
SAXIHP{0:3}AWREADY
SAXIACPAWREADY
O
MAXIGP{0,1}AWID[11:0] O SAXIGP{0,1}AWID[5:0]
SAXIHP{0:3}AWID[5:0]
SAXIACPAWID[2:0]
I
MAXIGP{0,1}AWLOCK[1:0] O SAXIGP{0,1}AWLOCK[1:0]
SAXIHP{0:3}AWLOCK[1:0]
SAXIACPAWLOCK[1:0]
I
MAXIGP{0,1}AWCACHE[3:0] O SAXIGP{0,1}AWCACHE[3:0]
SAXIHP{0:3}AWCACHE[3:0]
SAXIACPAWCACHE[3:0]
I
MAXIGP{0,1}AWPROT[2:0] O SAXIGP{0,1}AWPROT[2:0]
SAXIHP{0:3}AWPROT[2:0]
SAXIACPAWPROT[2:0]
I
MAXIGP{0,1}AWLEN[3:0] O SAXIGP{0,1}AWLEN[3:0]
SAXIHP{0:3}AWLEN[3:0]
SAXIACPAWLEN[3:0]
I
MAXIGP{0,1}AWSIZE[1:0] O SAXIGP{0,1}AWSIZE[1:0]
SAXIHP{0:3}AWSIZE[2:0]
SAXIACPAWSIZE[2:0]
I
MAXIGP{0,1}AWBURST[1:0] O SAXIGP{0,1}AWBURST[1:0]
SAXIHP{0:3}AWBURST[1:0]
SAXIACPAWBURST[1:0]
I
MAXIGP{0,1}AWQOS[3:0] O SAXIGP{0,1}AWQOS[3:0]
SAXIHP{0:3}AWQOS[3:0]
SAXIACPAWQOS[3:0]
I
~~
~
SAXIACPAWUSER[4:0]
I
Write Data
MAXIGP{0,1}WDATA[31:0] O SAXIGP{0,1}WDATA[31:0]
SAXIHP{0:3}WDATA[63:0]
SAXIACPWDATA[63:0]
I
MAXIGP{0,1}WVALID O SAXIGP{0,1}WVALID
SAXIHP{0:3}WVALID
SAXIACPWVALID
I
MAXIGP{0,1}WREADY I SAXIGP{0,1}WREADY
SAXIHP{0:3}WREADY
SAXIACPWREADY
O
Table 5-9: AXI Signals Summary (Cont’d)
AXI Channel
AXI PS Masters AXI PS Slaves
M_AXI_GP{0,1} I/O
S_AXI_GP{0,1}
S_AXI_HP{0:3}
S_AXI_ACP
I/O
