Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1412
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
Register reg2_ev_counter1 Details
Register (L2Cpl310) reg2_ev_counter0
Register reg2_ev_counter0 Details
Register (L2Cpl310) reg2_int_mask
Description Enable the programmer to read off the counter value. The counter counts
an event as specified by the Counter Configuration Registers. The counter
can be preloaded if counting is disabled and reset by the Event Counter
Control Register.
Field Name Bits Type Reset Value Description
counter_val 31:0 rw 0x0 Total of the event selected.
If a counter reaches its maximum value, it
saturates at that value until it is reset.
Name reg2_ev_counter0
Relative Address 0x00000210
Absolute Address 0xF8F02210
Width 32 bits
Access Type rw
Reset Value 0x00000000
Description Enable the programmer to read off the counter value. The counter counts
an event as specified by the Counter Configuration Registers. The counter
can be preloaded if counting is disabled and reset by the Event Counter
Control Register.
Field Name Bits Type Reset Value Description
counter_val 31:0 rw 0x0 Total of the event selected.
If a counter reaches its maximum value, it
saturates at that value until it is reset.
Name reg2_int_mask
Relative Address 0x00000214
Absolute Address 0xF8F02214
Width 32 bits
Access Type mixed
Reset Value 0x00000000
