Appendix B: Register Details
Register reg7_clean_pa Details
Register (L2Cpl310) reg7_clean_index
Register reg7_clean_index Details
Register (L2Cpl310) reg7_clean_way
Field Name Bits Type Reset Value Description
tag 31:12 rw 0x0 tag
index 11:5 rw 0x0 index
reserved 4:1 waz 0x0 reserved
c 0 rw 0x0 C Flag
When written must be 0.
When read, indicates that a background operation
is in progress
Name reg7_clean_index
Relative Address 0x000007B8
Absolute Address 0xF8F027B8
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description Clean Line by Set/Way Write the specific L2 cache line within the specified way to
L3 main memory if the line is
marked as valid and dirty. The line is marked as not dirty. The valid bit is unchanged
Field Name Bits Type Reset Value Description
reserved 31 waz 0x0 reserved
way 30:28 rw 0x0 way
reserved 27:12 waz 0x0 reserved
index 11:5 rw 0x0 index
reserved 4:1 waz 0x0 reserved
c0rw0x0c
Name reg7_clean_way
Relative Address 0x000007BC
Absolute Address 0xF8F027BC
Width 32 bits
