Appendix B: Register Details
Register reg9_d_lockdown3 Details
Register (L2Cpl310) reg9_i_lockdown3
Register reg9_i_lockdown3 Details
Register (L2Cpl310) reg9_d_lockdown4
Register reg9_d_lockdown4 Details
Field Name Bits Type Reset Value Description
reserved 31:16 waz,r
az
0x0 reserved
reserved 15:0 rw 0x0 reserved
Name reg9_i_lockdown3
Relative Address 0x0000091C
Absolute Address 0xF8F0291C
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description instruction lock down 3
Field Name Bits Type Reset Value Description
reserved 31:16 waz,r
az
0x0 reserved
reserved 15:0 rw 0x0 reserved
Name reg9_d_lockdown4
Relative Address 0x00000920
Absolute Address 0xF8F02920
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description data lock down 4
Field Name Bits Type Reset Value Description
reserved 31:16 waz,r
az
0x0 reserved
DATALOCK100 15:0 rw 0x0 Use for ACP master with SAXIACPAxID[2:1]=00
