Appendix B: Register Details
Register reg9_i_lockdown6 Details
Register (L2Cpl310) reg9_d_lockdown7
Register reg9_d_lockdown7 Details
Register (L2Cpl310) reg9_i_lockdown7
Register reg9_i_lockdown7 Details
Field Name Bits Type Reset Value Description
reserved 31:16 waz,r
az
0x0 reserved
INSTRLOCK110 15:0 rw 0x0 Use for ACP master with SAXIACPAxID[2:1]=10
Name reg9_d_lockdown7
Relative Address 0x00000938
Absolute Address 0xF8F02938
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description data lock down 7
Field Name Bits Type Reset Value Description
reserved 31:16 waz,r
az
0x0 reserved
DATALOCK111 15:0 rw 0x0 Use for ACP master with SAXIACPAxID[2:1]=11
Name reg9_i_lockdown7
Relative Address 0x0000093C
Absolute Address 0xF8F0293C
Width 32 bits
Access Type mixed
Reset Value 0x00000000
Description instruction lock down 7
Field Name Bits Type Reset Value Description
reserved 31:16 waz,r
az
0x0 reserved
INSTRLOCK111 15:0 rw 0x0 Use for ACP master with SAXIACPAxID[2:1]=11
