Appendix B: Register Details
Register reg9_unlock_way Details
Register (L2Cpl310) reg12_addr_filtering_start
Register reg12_addr_filtering_start Details
Register (L2Cpl310) reg12_addr_filtering_end
Field Name Bits Type Reset Value Description
reserved 31:16 waz,r
az
0x0 reserved
unlock_all_lines_by_w
ay_operation
15:0 rw 0x0 For all bits:
0 = Unlock all lines disabled. This is the default.
1 = Unlock all lines operation in progress for the
corresponding way.
Name reg12_addr_filtering_start
Relative Address 0x00000C00
Absolute Address 0xF8F02C00
Width 32 bits
Access Type mixed
Reset Value 0x40000001
Description When two masters are implemented, you can redirect a whole address range to
master 1 (M1).
When address_filtering_enable is set, all accesses with address >=
address_filtering_start and <address_filtering_end are automatically directed to M1.
All other accesses are directed to M0.
This feature is programmed using two registers.
Field Name Bits Type Reset Value Description
addr_filtering_start 31:20 rw 0x400 Address filtering start address.
reserved 19:1 waz,r
az
0x0 reserved
addr_filtering_enable 0 rw 0x1 0 = Address filtering disabled.
1 = Address filtering enabled
Name reg12_addr_filtering_end
Relative Address 0x00000C04
Absolute Address 0xF8F02C04
Width 32 bits
Access Type mixed
