Zynq-7000 AP SoC Technical Reference Manual www.xilinx.com 1434
UG585 (v1.11) September 27, 2016
Appendix B: Register Details
B.24 Application Processing Unit (mpcore)
Register Summary
Module Name Application Processing Unit (mpcore)
Software Name XSCU
Base Address 0xF8F00000 mpcore
Description Mpcore - SCU, Interrupt controller, Counters and Timers
Vendor Info ARM
Register Name Address Width Type Reset Value Description
SCU_CONTROL_REGI
STER
0x00000000 32 rw 0x00000002 SCU Control Register
SCU_CONFIGURATIO
N_REGISTER
0x00000004 32 ro 0x00000501 SCU Configuration Register
SCU_CPU_Power_Stat
us_Register
0x00000008 32 rw 0x00000000 SCU CPU Power Status Register
SCU_Invalidate_All_R
egisters_in_Secure_Stat
e
0x0000000C 32 wo 0x00000000 SCU Invalidate All Registers in
Secure State
Filtering_Start_Addres
s_Register
0x00000040 32 rw 0x00100000 Filtering Start Address Register
Filtering_End_Address
_Register
0x00000044 32 rw 0x00000000 Defined by FILTEREND input
SCU_Access_Control_
Register_SAC
0x00000050 32 rw 0x0000000F SCU Access Control (SAC)
Register
SCU_Non_secure_Acce
ss_Control_Register
0x00000054 32 ro 0x00000000 SCU Non-secure Access Control
Register
SNSAC
ICCICR
0x00000100 32 rw 0x00000000 CPU Interface Control Register
ICCPMR
0x00000104 32 rw 0x00000000 Interrupt Priority Mask Register
ICCBPR
0x00000108 32 rw 0x00000002 Binary Point Register
ICCIAR
0x0000010C 32 rw 0x000003FF Interrupt Acknowledge Register
ICCEOIR
0x00000110 32 rw 0x00000000 End Of Interrupt Register
ICCRPR
0x00000114 32 rw 0x000000FF Running Priority Register
ICCHPIR
0x00000118 32 rw 0x000003FF Highest Pending Interrupt
Register
ICCABPR
0x0000011C 32 rw 0x00000003 Aliased Non-secure Binary
Point Register
